Tata Hitachi ZAXIS 470H Excavator

The Tata Hitachi ZAXIS 470H excavator is ideal for construction, infrastructure development, and waste management. This machine is built to tackle various tasks such as digging, trenching, excavating, loading, and unloading materials.

Powered by a turbocharged diesel engine, this machine offers maximum output and minimal maintenance. Its advanced hydraulic system delivers quick work and smooth operation.

The Tata Hitachi ZAXIS 470H excavator has a 3.1 m³ large backhoe bucket, and its maximum forward speed is up to 5.1 km/h. These features deliver strength, speed, and stability in any terrain.

*Ex-Showroom Price

₹ 1.17 - 1.20 Crore

Tata Hitachi ZAXIS 470H Key Specifications

Tata Hitachi ZAXIS 470H Features

Engine

Model ISUZU AA-6WG1TQA

Type 4-Cycle water-cooled, direct injection

Engine gross Power 315 HP @ 1800 rpm

Max. Torque 1275 Nm @ 1500 rpm

Displacement 15.681 L

Undercarriage

No. of Shoes 49

No. of Upper Rollers 2

No. of Bottom Rollers 8

Track Shoe Width 600 mm

Swing System

Max. Swing Speed 9.0 rpm

Min. Swing Radius 3930-5000 mm

Drive and Brake

Max. Travel Speed 5.1 km/h

Gradeability 35°(70%)

Hydraulic System

Main Pump Type 2 Variable displacements axial piston pumps

Main Pump max. Oil Flow 2x360 lpm

Swing Circuit 290 kgf/cm²

Travel Circuit 360 kgf/cm²

Refill Capacity

Fuel Tank Capacity 705 L

Engine Oil and Filter 55 L

Hydraulic System 510 L

Hydraulic Tank Capacity 310 L

Weight and Ground Pressure

Operating Weight 47100-47500 kg

Ground Pressure 0.894-0.902 kgf/cm²

Dimensions

Overall Length 12110 mm

Overall Height 3170 mm

Bucket Capacity 1.9-3.1 m³

Track Gauge 2740 mm

Ground Clearance 495 mm

Working Ranges

Max. Dumping Height 7190-10900 mm

Max. Digging Depth 5920-11100 mm

Max. Vertical Wall Digging Depth 4150-10340 mm

Max. Digging Reach 10460-15120 mm

Max. Digging Reach at Ground Level 10240-14960 mm

Boom Length 6.3 m

Arm Length 2.5-7.0 m

Bucket Digging Force 20470-29130 kgf

Arm Crowding Force 12440-30520 kgf

Top Applications of Tata Hitachi ZAXIS 470H

1. Agriculture

The Tata Hitachi ZAXIS 470H excavator's superior engine improves fuel efficiency at lower operating costs in agriculture operations.

2. Utility Installations

The Tata Hitachi ZAXIS 470H excavator has a 3.1 m³ bucket capacity that efficiently handles large amounts of material and reduces the number of digging cycles.

3. Construction

The Tata Hitachi ZAXIS 470H excavator comes with a large fuel tank capacity that can help in working longer hours without frequently refuelling in construction projects.

4. Waste Management

Its operating capacity easily lifts heavy loads and dumps trash into trucks and improves stability.

5. Road Construction

The Tata Hitachi ZAXIS 470H excavator’s digging depth capabilities minimise repositioning of the machine and provide efficient digging on road construction.

Why Choose MachineWale for Tata Hitachi ZAXIS 470H in India?

MachineWale allows you to compare the Tata Hitachi ZAXIS 470H with different backhoe loader models. We offer a platform that gives you information from machine’s specifications and features to images and dealer listings. Additionally, you can list your used equipment for sell or rent and get genuine buyers and renters across India.
