Tata Hitachi Nx 30 Mini Excavator is a powerful and efficient machine that redefines versatility in the heavy-duty machinery sector. Whether you are engaged in construction, tackling infrastructure projects, or working in agriculture, the Tata Hitachi Nx 30 stands out as a reliable partner for all your endeavors. With its exceptional performance, innovative features, and commitment to efficiency, the Nx 30 is engineered to handle a wide range of tasks with precision and ease, making it an indispensable asset for various industries. Tata Hitachi Nx 30 features an impressive engine gross power of 27.4 HP and weighs 2900 kg, offering a robust and reliable option for operators seeking performance without sacrificing mobility. With a bucket capacity ranging from 0.04 m³ to 0.07 m³, this mini excavator is versatile enough to handle both heavy-duty and smaller tasks. Its bucket digging force of 2325 kgf excels in tough digging conditions, delivering outstanding results on construction sites and agricultural projects alike. Additionally, the maximum digging depth of 2357 mm enhances its utility, allowing operators to reach deeper without the need for multiple passes, making the Tata Hitachi Nx 30 an essential asset for any job. Tata Hitachi Nx 30 Mini Excavator is its innovative Quadra Flow Hydraulic System, ensuring maximum efficiency and effectiveness in every operation. Additionally, the factory-fitted rock breaker piping kit simplifies the attachment of rock-breaking equipment, allowing you to tackle tough materials effortlessly. The Tata Hitachi Nx 30 also boasts minimal fuel consumption, making it a cost-effective choice for operators looking to reduce operational expenses. Coupled with the lowest maintenance costs in its class, this mini excavator provides long-term savings while maintaining peak performance.

Tata Hitachi NX30 Key Specifications

Tata Hitachi NX30 Features

Engine
Model Yanmar 3TNV88-BSTAH
Type Water cooled, 3-cylinder diesel engine, direct injection
Engine Gross Power 20.4 kW @ 2200 rpm
Max. Torque 106 Nm @ 1200 rpm
Displacement 1642 L
Undercarriage
No. of Shoes 40
No. of Upper Rollers 1
No. of Bottom Rollers 3
Track Shoe Width 280 mm
Swing System
Max. Swing Speed 10.5 rpm
Min. Swing Radius 2107 mm
Drive and Brake
Max. Travel Speed 3.2 km/h
Gradeability 30°(58%)
Hydraulic System
Main Pump max. Oil Flow 8.8 lpm
Swing Circuit 145 kgf/cm2
Travel Circuit 175 kgf/cm2
Refill Capacity
Fuel Tank Capacity 32 L
Engine Oil and filter 6.7 L
Hydraulic System 67 L
Hydraulic Oil Capacity 42 L
Weight and Ground Pressure
Operating Weight 2900 kg
Dimensions
Overall Length 4150 mm
Overall Height 2527 mm
Bucket Capacity 0.04 - 0.07 m³
Track Gauge 1220 mm
Ground Clearance 268 mm
Working Ranges
Max. Dumping Height 2666 mm
Max. Digging Depth 2625 mm
Max. Vertical Wall Digging Depth 1862 mm
Max. Digging Reach 4555 mm
Max. Digging Reach at Ground Level 4428 mm
Boom Length 2100 mm
Arm Length 1200 mm
Bucket Digging Force 2325 kgf
Arm Crowding Force 1460 kgf
