Hyundai R150L SMART PLUS

Hyundai R150L Smart Plus Hydraulic Excavator is designed for versatility and excels in various applications, including foundation work, pavement removal, slope stabilization, and flood control. Its robust performance makes it ideal for digging deep and stable foundations, ensuring strong support for structures. R150L Smart Plus Hydraulic Excavator efficiently removes old pavement, facilitating road upgrades and repairs while minimizing disruption. Additionally, it is essential for projects requiring grading and stabilization of slopes, enhancing safety and durability in construction. Furthermore, the Hyundai R150L Smart Plus plays a critical role in flood management efforts, aiding in the construction of levees and drainage systems to effectively control water flow. Hyundai R150L Smart Plus features impressive key specifications, including an engine gross power of 105 hp, a substantial fuel tank capacity of 270 liters for extended operation, and a maximum digging depth ranging from 5150 to 5550 mm, allowing it to handle a variety of tasks efficiently. With an operating weight of 14,200 kg, this excavator is engineered for robustness and stability, making Hyundai R150L Smart Plus Hydraulic Excavator a reliable choice for demanding construction projects. Hyundai R150L Smart Plus Hydraulic Excavator is designed for heavy-duty operations, featuring a powerful engine that ensures optimal performance and reliability while its substantial fuel tank capacity allows for extended work hours, minimizing downtime for refueling. Key unique selling points include a Pump Flow Control System that optimizes hydraulic flow for enhanced efficiency, an Arm Regeneration System that recycles hydraulic oil during boom lowering for faster cycle times and reduced fuel consumption, and an Exclusive Breaker Mode that optimizes hydraulic flow for demolition tasks. Additionally, the Power Boost System delivers extra hydraulic power on demand, providing the necessary force for challenging tasks such as breaking and digging into tough materials.

Hyundai R150L SMART PLUS Features

Engine
Model	Kirloskar 4R1040T	Engine Gross Power	105 HP @ 2200 rpm
Max. Torque	37.5 Nm @ 1500 rpm

Undercarriage
No. of Shoes	46	No. of Upper Rollers	1
No. of Bottom Rollers	7	Track Shoe Width	600 mm

Swing System
Max. Swing Speed	12.0 rpm	Min. Swing Radius	2670 mm

Drive and Brake
Max. Travel Speed	5.5 km/h	Gradeability	70% (35°)

Hydraulic System
Main Pump Type	2 Variable Displacement Piston Pumps	Main Pump max. Oil Flow	2 x 130 LPM
Swing Circuit	285 kg/cm²	Travel Circuit	350 kg/cm²

Refill Capacity
Fuel Tank Capacity	270 L	Engine Oil and Filter	11.5 L
Hydraulic System	210 L	Hydraulic Tank Capacity	124 L

Weight and Ground Pressure
Operating Weight	14200 kg	Ground Pressure	0.36 kg/cm²

Dimensions
Overall Length	7870 mm	Overall Height	2860 mm
Bucket Capacity	0.72 m³	Track Gauge	2000 mm
Ground Clearance	440 mm

Working Ranges
Max. Dumping Height	5750 mm	Max. Digging Depth	5150 mm
Max. Vertical Wall Digging Depth	4900 mm	Max. Digging Reach	7920 mm
Max. Digging Reach at Ground Level	7770 mm	Boom Length	4600 mm
Arm Length	2100 mm	Bucket Digginge Force	8900-10400 kgf
Arm Crowding Force	7500-7900 kgf

Engine
Model	Kirloskar 4R1040T
Engine Gross Power	105 HP @ 2200 rpm
Max. Torque	37.5 Nm @ 1500 rpm

Undercarriage
No. of Shoes	46
No. of Upper Rollers	1
No. of Bottom Rollers	7
Track Shoe Width	600 mm

Swing System
Max. Swing Speed	12.0 rpm
Min. Swing Radius	2670 mm

Drive and Brake
Max. Travel Speed	5.5 km/h
Gradeability	70% (35°)

Hydraulic System
Main Pump Type	2 Variable Displacement Piston Pumps
Main Pump max. Oil Flow	2 x 130 LPM
Swing Circuit	285 kg/cm²
Travel Circuit	350 kg/cm²

Refill Capacity
Fuel Tank Capacity	270 L
Engine Oil and Filter	11.5 L
Hydraulic System	210 L
Hydraulic Tank Capacity	124 L

Weight and Ground Pressure
Operating Weight	14200 kg
Ground Pressure	0.36 kg/cm²

Dimensions
Overall Length	7870 mm
Overall Height	2860 mm
Bucket Capacity	0.72 m³
Track Gauge	2000 mm
Ground Clearance	440 mm

Working Ranges
Max. Dumping Height	5750 mm
Max. Digging Depth	5150 mm
Max. Vertical Wall Digging Depth	4900 mm
Max. Digging Reach	7920 mm
Max. Digging Reach at Ground Level	7770 mm
Boom Length	4600 mm
Arm Length	2100 mm
Bucket Digginge Force	8900-10400 kgf
Arm Crowding Force	7500-7900 kgf
