Hyundai HX 360L

Hyundai HX 360L Hydraulic Excavator excels in a variety of applications, making it an essential machine for numerous projects. It is ideal for foundation work, efficiently excavating and preparing sites for building foundations to ensure stability and accuracy. In road construction and maintenance, it proves invaluable for pavement removal, easily handling concrete and asphalt. The HX 360L Hydraulic Excavator also plays a critical role in slope stabilization, providing the necessary power and precision to reshape and stabilize slopes, preventing erosion and ensuring safety. Additionally, Hyundai HX 360L is equipped to tackle excavation tasks related to flood control, enabling effective drainage and water management strategies to mitigate flooding risks. Hyundai HX 360L boasts impressive specifications that enhance its operational capabilities across various applications. It features an engine gross power of 194 kW, ensuring robust performance for demanding tasks. With a fuel tank capacity of 600 liters, HX 360L Hydraulic Excavator is designed for extended operation without frequent refueling. The excavator achieves a maximum digging depth of 6,820 mm, making Hyundai HX 360L Hydraulic Excavator highly effective for deep excavation projects. Weighing in at 35,500 kg, it offers excellent stability and durability, suitable for a range of heavy-duty applications. Hyundai HX 360L Hydraulic Excavator is distinguished by several unique selling points that enhance its performance and efficiency. Its advanced diesel engine, the Hyundai HM8.3, incorporates direct injection and mechanical control to deliver exceptional fuel efficiency while minimizing emissions without compromising on power. The two-speed axial piston motor features a brake valve and parking brake, offering enhanced control and stability, particularly on steep or uneven terrain. For added safety and operational efficiency, the automatic brake swing motor allows for precise control during swinging motions. Additionally, the fully hydrostatic drive system enables smooth acceleration and deceleration, making Hyundai HX 360L easy for operators to maneuver the excavator accurately, even in confined spaces.

Hyundai HX 360L Features

Engine
Model	Hyundai HM8.3	Type	Water Cooled, 4 Cycle, Turbocharged, Charge Air Cooled, Direct Injection
Engine Gross Power	261 HP(195 KW) @ 2000 rpm	Max. Torque	1150 Nm @ 1300 rpm
Displacement	8.3 L

Undercarriage
No. of Shoes	48	No. of Upper Rollers	2
No. of Bottom Rollers	8	Track Shoes Width	600 mm

Swing System
Max. Swing Speed	11.2 rpm	Min. Swing Radius	4620 mm

Drive and Brake
Max. Travel Speed	5 km/h	Gradeability	70% (35°)

Hydraulic System
Main Pump Type	Variable Displacement Tandem Axial Piston Pumps	Main Pump max. Oil Flow	2 x 315 LPM
Swing Circuit	300 kg/cm²	Travel Circuit	350 kg/cm²

Refill Capacity
Fuel Tank Capacity	600 L	Engine Oil and Filter	26.5 L
Hydraulic System	414 L	Hydraulic Tank Capacity	210 L

Weight and Ground Pressure
Operating Weight	35500 kg	Ground Pressure	0.68 kg/cm²

Dimensions
Overall Length	11340 mm	Overall Height	3760 mm
Bucket Capacity	1.80-2.10 m³	Track Gauge	2590 mm
Ground Clearance	500 mm

Working Ranges
Max. Dumping Height	7120 mm	Max. Digging Depth	6820 mm
Max. Vertical Wall Digging Depth	6320 mm	Max. Digging Reach	10710 mm
Max. Digging Reach at Ground Level	10580 mm	Boom Length	6450 mm
Arm Length	2650 mm	Bucket Digging Force	19100-21600 kgf
Arm Crowding Force	17900-19400 kgf

Engine
Model	Hyundai HM8.3
Type	Water Cooled, 4 Cycle, Turbocharged, Charge Air Cooled, Direct Injection
Engine Gross Power	261 HP(195 KW) @ 2000 rpm
Max. Torque	1150 Nm @ 1300 rpm
Displacement	8.3 L

Undercarriage
No. of Shoes	48
No. of Upper Rollers	2
No. of Bottom Rollers	8
Track Shoes Width	600 mm

Swing System
Max. Swing Speed	11.2 rpm
Min. Swing Radius	4620 mm

Drive and Brake
Max. Travel Speed	5 km/h
Gradeability	70% (35°)

Hydraulic System
Main Pump Type	Variable Displacement Tandem Axial Piston Pumps
Main Pump max. Oil Flow	2 x 315 LPM
Swing Circuit	300 kg/cm²
Travel Circuit	350 kg/cm²

Refill Capacity
Fuel Tank Capacity	600 L
Engine Oil and Filter	26.5 L
Hydraulic System	414 L
Hydraulic Tank Capacity	210 L

Weight and Ground Pressure
Operating Weight	35500 kg
Ground Pressure	0.68 kg/cm²

Dimensions
Overall Length	11340 mm
Overall Height	3760 mm
Bucket Capacity	1.80-2.10 m³
Track Gauge	2590 mm
Ground Clearance	500 mm

Working Ranges
Max. Dumping Height	7120 mm
Max. Digging Depth	6820 mm
Max. Vertical Wall Digging Depth	6320 mm
Max. Digging Reach	10710 mm
Max. Digging Reach at Ground Level	10580 mm
Boom Length	6450 mm
Arm Length	2650 mm
Bucket Digging Force	19100-21600 kgf
Arm Crowding Force	17900-19400 kgf
