| Technical Data | |||
|---|---|---|---|
| Gross Vehicle Weight | 28,000 kg | Engine | Cummins 6.7L OBD-|| |
| Engine Capacity | 6,702 cc | Max. Power | 224 KW @ 2,300 rpm |
|
|
|||
| Technical Data | |
|---|---|
| Gross Vehicle Weight | 28,000 kg |
| Engine | Cummins 6.7L OBD-|| |
| Engine Capacity | 6,702 cc |
| Max. Power | 224 KW @ 2,300 rpm |
| Max. Torque | 1,200 Nm @ 1,200 - ,1500 rpm |
| Clutch | 430 mm |
| Frame | Heavy duty straight frame with riveted / Bolted Cross members |
| Transmission | TATA G1350 |
| Front Axle | Heavy duty forged | beam Reverse Elliot type |
| Rear Axle | Hub Reduction Transmission |
| Rear Suspension | Bogie |
| Body Size (cu.m) | 16 Box / 16 Scoop |
| Configuration | 6 x 4 |
| Cab/Cowl | PRIMA Day Cab |
| Tyres | 11 x 20 MT, 12 x 24 MT |
| Ventilation | AC |
| Fuel Tank Capacity | 300 L HDPE |
| Wheel Base Options | 39 WB |
| No. of Tyres | 10 Tyres |
|
|
|
