Tata Hitachi EX 215 LC Prime

Tata Hitachi EX 215 LC Prime Hydraulic Excavator combines cutting-edge technology with unmatched performance, making it ideal for modern industrial operations. EX 215 LC Prime machine is designed for diverse applications such as mining, construction, infrastructure development, and solid waste management. Built for robustness and power, the EX 215 LC Prime delivers excellent performance across various demanding tasks. Tata Hitachi EX 215 LC Prime is powered by a 140 HP engine, delivering impressive strength for heavy-duty tasks. Its operating weight ranges from 20,800 to 21,900 KG, making it well-suited for large-scale operations. With a bucket capacity of 1.05 to 1.70 m³ and a bucket digging force of 12,250 kgf, it ensures superior digging capabilities and boosts productivity on the field. Its maximum digging depth of 5,910 mm allows for precise, deep excavations, making it ideal for challenging projects. Tata Hitachi EX 215 LC Prime stands out with its innovative hydraulic flow combination, enabling efficient operation of attachments and improved overall machine performance. Designed for versatility, Tata Hitachi EX 215 LC Prime excavator offers three selectable work modes—E (Economy), S (Standard), and P (Power)—which allow for optimal performance in mining, construction, infrastructure development, and waste management. Powered by a 140 HP engine, EX 215 LC Prime Hydraulic Excavator handles heavy-duty tasks with ease. Its fuel-saving pump system and hydraulic regeneration further enhance fuel efficiency, reducing operational costs while ensuring high productivity in large-scale projects.

Tata Hitachi EX 215 LC Prime Features

Engine
Model	Cummins 6BT5.9C	Type	6 Cylinder water cooled, direct injection
Engine Gross Power	140 Hp @ 2000 rpm	Max. Torque	566 Nm @ 1600 rpm

Undercarriage
No. of Shoes	49	No. of Upper Rollers	2
No. of Bottom Rollers	8	Track Shoe Width	600

Swing System
Max. Swing Speed	13.3 rpm	Min. Swing Radius	3720 mm

Drive and Brake
Max. Travel Speed	4.2 km/h	Gradeability	35°(70%)

Hydraulic System
Main Pump Type	2 Variable displacements axial piston pumps	Main Pump max. Oil Flow	2x221 lpm
Swing Circuit	275 kgf/cm²	Travel Circuit	350 kgf/cm²

Refill Capacity
Fuel Tank Capacity	300 L	Engine Oil and Filter	22 L
Hydraulic System	220 L	Hydraulic Tank Capacity	129 L

Weight and Ground Pressure
Operating Weight	20800-21900 kg	Ground Pressure	0.44-0.46 kgf/cm²

Dimensions
Overall Length	9720 mm	Overall Height	2850 mm
Bucket Capacity	1.05-1.7 m³	Track Gauge	2390 mm
Ground Clearance	450 mm

Working Ranges
Max. Dumping Height	6230 mm	Max. Digging Depth	5910 mm
Max. Vertical Wall Digging Depth	5050 mm	Max. Digging Reach	9250 mm
Max. Digging Reach at Ground Level	9060 mm	Boom Length	5680 mm
Arm Length	2200 mm	Bucket Digging Force	12250 kgf
Arm Crowding Force	11700 kgf

Engine
Model	Cummins 6BT5.9C
Type	6 Cylinder water cooled, direct injection
Engine Gross Power	140 Hp @ 2000 rpm
Max. Torque	566 Nm @ 1600 rpm

Undercarriage
No. of Shoes	49
No. of Upper Rollers	2
No. of Bottom Rollers	8
Track Shoe Width	600

Swing System
Max. Swing Speed	13.3 rpm
Min. Swing Radius	3720 mm

Drive and Brake
Max. Travel Speed	4.2 km/h
Gradeability	35°(70%)

Hydraulic System
Main Pump Type	2 Variable displacements axial piston pumps
Main Pump max. Oil Flow	2x221 lpm
Swing Circuit	275 kgf/cm²
Travel Circuit	350 kgf/cm²

Refill Capacity
Fuel Tank Capacity	300 L
Engine Oil and Filter	22 L
Hydraulic System	220 L
Hydraulic Tank Capacity	129 L

Weight and Ground Pressure
Operating Weight	20800-21900 kg
Ground Pressure	0.44-0.46 kgf/cm²

Dimensions
Overall Length	9720 mm
Overall Height	2850 mm
Bucket Capacity	1.05-1.7 m³
Track Gauge	2390 mm
Ground Clearance	450 mm

Working Ranges
Max. Dumping Height	6230 mm
Max. Digging Depth	5910 mm
Max. Vertical Wall Digging Depth	5050 mm
Max. Digging Reach	9250 mm
Max. Digging Reach at Ground Level	9060 mm
Boom Length	5680 mm
Arm Length	2200 mm
Bucket Digging Force	12250 kgf
Arm Crowding Force	11700 kgf
