Tata Hitachi EX 210 Infra Super Plus Excavator

The Tata Hitachi EX 210 Infra Super Plus excavator is designed for a wide range of applications such as utility installation, quarrying, mining, road construction, and forestry. Additionally, it handles various tasks like material handling, lifting heavy loads, snow removal, building foundations, and dumping materials.

The Tata Hitachi EX 210 Infra Super Plus, combined with a Cummins 6BT5.9C diesel engine, provides high performance and fuel efficiency. Its advanced hydraulic system offers smooth operations without sacrificing performance.

Its powerful engine generates 131 HP at 2000 rpm and 300 L fuel tank capacity, delivering lower fuel consumption and enhanced productivity.

*Ex-Showroom Price

Coming Soon

Tata Hitachi EX 210 Infra Super Plus Key Specifications

Tata Hitachi EX 210 Infra Super Plus Features

Engine

Model Cummins 6BT5.9C

Type 6 Cylinder in-line water cooled

Engine Gross Power 131 HP @ 2000 rpm

Max. Torque 537 Nm @ 1300 rpm

Undercarriage

No. of Shoes 45

No. of Upper Rollers 2

No. of Bottom Rollers 7

Track Shoe Width 600 mm

Swing System

Max. Swing Speed 13.7 rpm

Min. Swing Radius 3660-3720 mm

Drive and Brake

Max. Travel Speed 4.2 km/h

Gradeability 35° (70%)

Hydraulic System

Main Pump Type 2 Variable displacements axial piston pumps

Main Pump max. Oil Flow 2x221 lpm

Swing Circuit 275 kgf/cm²

Travel Circuit 350 kgf/cm²

Refill Capacity

Fuel Tank Capacity 300 L

Engine Oil and Filter 22 L

Hydraulic System 220 L

Hydraulic Tank Capacity 129 L

Weight and Ground Pressure

Operating Weight 20300 kg

Ground Pressure 0.47 kgf/cm²

Dimensions

Overall Length 9720 mm

Overall Height 2850 mm

Bucket Capacity 0.86-1.5 m³

Track Gauge 2390 mm

Ground Clearance 435 mm

Working Ranges

Max. Dumping Height 6230-6610 mm

Max. Digging Depth 5910-6600 mm

Max. Vertical Wall Digging Depth 5050-5980 mm

Max. Digging Reach 9250-9910 mm

Max. Digging Reach at Ground Level 9060-9740 mm

Boom Length 5680 mm

Arm Length 2200-2900 mm

Bucket Digging Force 12250 kgf

Arm Crowding Force 11700 kgf

Top Applications of Tata Hitachi EX 210 Infra Super Plus

1. Waste Management

The Tata Hitachi EX 210 Infra Super Plus's high-productive engine provides superior digging and lifting power in dump yards.

2. Forest Work

The Tata Hitachi EX 210 Infra Super Plus excavator's swing system allows faster material movement and saves time on repetitive tasks in forest activity.

3. Construction

Its huge backhoe bucket capacity helps you move more material in fewer cycles on the construction sites

4. Agriculture

The Tata Hitachi EX 210 Infra Super Plus's operating weight capacity easily handles heavy loads and heavy-duty work and reduces vibration during agricultural operations.

5. Quarrying Operations

The Tata Hitachi EX 210 Infra Super Plus excavator's 2.9 m longer arm and 5.6 m boom improve excavation accuracy and provide consistent performance.
