Sany SY60C
Sany SY60C

Sany SY60C

SANY SY60C Mini Excavator is a highly versatile machine designed for a wide range of applications, including slope stabilization, flood control, rubble removal, and environmental remediation. Its compact design and powerful hydraulics make it ideal for working in challenging terrains and confined spaces. Whether it's digging and grading for slope stabilization, building flood barriers, or clearing debris in urban settings, the SY60C Mini Excavator excels at providing the precision and performance needed for tough tasks. Additionally, its efficient digging and material handling capabilities ensure minimal disruption during environmental remediation projects, making SANY SY60C an essential tool for various demanding tasks.


SANY SY60C is equipped with a 28 hp engine, offering a balance of power and efficiency for various tasks. It has a maximum digging depth of 3.10 meters, making it suitable for a wide range of excavation and grading applications. With an operating weight of 3.78 tons, the SY60C Compact Excavator combines compact size with robust performance, allowing SANY SY60C Mini Excavator to maneuver easily in confined spaces while handling demanding work. The bucket capacity ranges from 0.12 cubic meters, providing versatility for tasks like digging, material handling, and site preparation.


SANY SY60C Mini Excavator stands out for its ability to operate efficiently in confined spaces, offering exceptional maneuverability in urban construction, flood control, and environmental remediation tasks. Its independent boom swing and boom offset capabilities allow it to work close to obstacles, making it ideal for rubble removal and slope stabilization projects where space is tight. Equipped with an advanced hydraulic system, the SY60C Mini Excavator delivers optimal flow and fuel efficiency, ensuring high performance and productivity across various demanding applications. Additionally, the SANY SY60C features multiple work modes and an auto idle function that reduces fuel consumption during idle periods, enhancing its cost-effectiveness for long-term operations.

Sany SY60C Key Specifications

Sany SY60C Features

Engine

Model Isuzu 4JG1
Type 4 Stroke, 4 cylinder, water cooled
Engine Gross Power 48.9 hp(36 kw) @ 2400 rpm
Max. Torque 175 Nm @ 1800 rpm
Displacement 3.05 L

Undercarriage

No. of Shoes 40
NO. of Upper Rollers 1
No. of Bottom Rollers 5
Track Shoe Width 400 mm

Swing System

Max. Swing Speed 10 rpm
Min. Swing Radius 2555 mm

Drive and Brake

Max. Travel Speed 3.7 km/h
Gradeability 35%(70°)

Hydraulic System

Main Pump Type Axial piston variable displacement pump
Main Pump max. Oil Flow 138 lpm
Swing Circuit 19.1 MPa
Travel Circuit 24.8 MPa

Refill Capacity

Fuel Tank Capacity 130 L
Engine Oil and Filter 9.6 L
Hydraulic Tank Capacity 85 L

Weight and Ground Pressure

Operating Weight 5780 kg
Ground Pressure 33 kPa

Dimensions

Overall Length 5925 mm
Overall Height 2595 mm
Bucket Capacity 0.26 m³
Track Gauge 1600 mm
Ground Clearance 330 mm

Working Ranges

Max. Dumping Height 3930 mm
Max. Digging Depth 3815 mm
Max. Vertical Wall Digging Depth 3070 mm
Max. Digging Reach 6090 mm
Boom Length 3000 mm
Arm Length 1550 mm
Bucket Digging Force 45 kN
Arm Crowding Force 33 kN
