Hyundai R85A SMART PLUS

Hyundai R85A Smart Plus Hydraulic Excavator excels in a wide range of applications, including crane support, mining, construction, and demolition. It is perfect for lifting and positioning tasks, easily supporting cranes and assisting in heavy lifting operations on construction sites. Its powerful digging capabilities make it ideal for mining operations, where efficient material handling is crucial. Additionally, whether for digging foundations, trenching, or site preparation, the R85A Smart Plus Hydraulic Excavator is built to meet the demands of various construction projects. Designed for heavy-duty work, this excavator can effectively tackle demolition tasks, making Hyundai R85A Smart Plus a versatile asset for any construction fleet. Hyundai R85A Smart Plus features key specifications that enhance its performance and efficiency in various tasks. It has an engine gross power of 56.7 kW, providing reliable and robust power for demanding operations. The fuel tank capacity is 135 liters, ensuring extended operational time without frequent refueling. With a maximum digging depth of 4205 mm, R85A Smart Plus Hydraulic Excavator is capable of handling deep excavation tasks effectively. The excavator has an operating weight of 8100 kg, contributing to its stability and strength during operation, making Hyundai R85A Smart Plus a valuable asset for construction, mining, and demolition projects. Hyundai R85A Smart Plus Hydraulic Excavator is designed for high efficiency and productivity, featuring a powerful hydraulic system with two variable displacement piston-type main pumps that optimize performance and fuel efficiency, allowing for quick cycle times on job sites. Its unique selling points include an axial piston motor drive for enhanced traction and power transfer, a pentagonal box-type track frame that improves stability and durability, and a multi wet disc parking brake for exceptional safety and reliability during operation and when stationary. This makes the Hyundai R85A Smart Plus a versatile and dependable choice for various applications, including construction, mining, and demolition.

Hyundai R85A SMART PLUS Features

Engine
Model	Kirloskar 4R1040NA	Engine Gross Power	76 HP(56.7 KW) @ 2200 rpm
Max. Torque	290 Nm @ 1320 rpm

Undercarriage
No. of Shoes	38	No. of Upper Rollers	1
No. of Bottom Rollers	5	Track Shoe Width	450 mm

Swing System
Max. Swing Speed	12.0 rpm	Min. Swing Radius	1786 mm

Drive and Brake
Max. Travel Speed	4.8 km/h	Gradeability	70% (35°)

Hydraulic System
Main Pump Type	2 Variable Displacement Piston Pumps	Main Pump max. Oil Flow	2 x 75.6 LPM
Swing Circuit	210 kg/cm²	Travel Circuit	280 kg/cm²

Refill Capacity
Fuel Tank Capacity	135 L	Engine Oil and Filter	11.5 L
Hydraulic System	130 L	Hydraulic Tank Capacity	75 L

Weight and Ground Pressure
Operating Weight	8100 kg	Ground Pressure	0.38 kg/cm²

Dimensions
Overall Length	6110 mm	Overall Height	2750 mm
Bucket Capacity	0.35 m³	Track Gauge	1750 mm
Ground Clearance	360 mm

Working Ranges
Max. Dumping Height	5096 mm	Max. Digging Depth	4205 mm
Max. Vertical Wall Digging Depth	3312 mm	Max. Digging Reach	6287 mm
Max. Digging Reach at Ground Level	6151 mm	Boom Length	3700 mm
Arm Length	1670 mm	Bucket Digging Force	4260-5250 kgf
Arm Crowding Force	3874-3943 kgf

Engine
Model	Kirloskar 4R1040NA
Engine Gross Power	76 HP(56.7 KW) @ 2200 rpm
Max. Torque	290 Nm @ 1320 rpm

Undercarriage
No. of Shoes	38
No. of Upper Rollers	1
No. of Bottom Rollers	5
Track Shoe Width	450 mm

Swing System
Max. Swing Speed	12.0 rpm
Min. Swing Radius	1786 mm

Drive and Brake
Max. Travel Speed	4.8 km/h
Gradeability	70% (35°)

Hydraulic System
Main Pump Type	2 Variable Displacement Piston Pumps
Main Pump max. Oil Flow	2 x 75.6 LPM
Swing Circuit	210 kg/cm²
Travel Circuit	280 kg/cm²

Refill Capacity
Fuel Tank Capacity	135 L
Engine Oil and Filter	11.5 L
Hydraulic System	130 L
Hydraulic Tank Capacity	75 L

Weight and Ground Pressure
Operating Weight	8100 kg
Ground Pressure	0.38 kg/cm²

Dimensions
Overall Length	6110 mm
Overall Height	2750 mm
Bucket Capacity	0.35 m³
Track Gauge	1750 mm
Ground Clearance	360 mm

Working Ranges
Max. Dumping Height	5096 mm
Max. Digging Depth	4205 mm
Max. Vertical Wall Digging Depth	3312 mm
Max. Digging Reach	6287 mm
Max. Digging Reach at Ground Level	6151 mm
Boom Length	3700 mm
Arm Length	1670 mm
Bucket Digging Force	4260-5250 kgf
Arm Crowding Force	3874-3943 kgf
