Hyundai R140L SMART PLUS

Hyundai R140L Smart Hydraulic Excavator is designed to excel in various applications, including waste management, forestry, marine construction, and snow removal. In waste management, it efficiently handles disposal and recycling tasks, contributing to a cleaner environment. For forestry, the R140L Smart Hydraulic Excavator is ideal for tree clearing and site preparation, enhancing productivity in timber harvesting. Its capabilities extend to marine construction, where it performs dredging and shoreline restoration tasks, making it versatile for aquatic projects. Additionally, the Hyundai R140L Smart effectively manages snow clearing operations in urban areas, ensuring safe access during winter months. Hyundai R140L Smart is powered by a robust engine that delivers 105 horsepower, ensuring strong performance across various tasks. With a fuel tank capacity of 270 liters, it is designed for extended operational periods without frequent refueling. The R140L Smart Hydraulic Excavator offers a maximum digging depth of 5,150 mm, enabling it to handle deeper excavation tasks efficiently. Weighing 14,000 kg, this machine combines power and stability, making Hyundai R140L Smart Hydraulic Excavator well-suited for demanding applications in waste management, forestry, marine construction, and snow removal. Hyundai R140L Smart Hydraulic Excavator is powered by a high-performance Kirloskar 4R1040T Diesel Engine, ensuring exceptional performance and fuel efficiency. Its significant fuel tank capacity supports extended operations, making R140L Smart Hydraulic Excavator perfect for projects that demand long work hours without frequent refueling. Hyundai R140L Smart is equipped with an advanced hydraulic system featuring two variable displacement piston pumps, which enhances precision and control during lifting and digging tasks, thus boosting overall productivity. Additionally, its fully hydrostatic drive system allows for smooth operation and superior maneuverability on challenging job sites, while the axial piston motor in-shoe type drive motor ensures optimal power transfer, contributing to the machine's robust performance and durability across diverse applications.

Hyundai R140L SMART PLUS Features

Engine
Model	Kirloskar 4R1040T	Engine Gross Power	105 Hp @ 2200 rpm
Max. Torque	37.5 Nm @ 1500 rpm

Undercarriage
No. of Shoes	46	No. of Upper Rollers	1
No. of Bottom Rollers	7	Track Shoe Width	500 mm

Swing System
Max. Swing Speed	12.0 rpm	Min. Swing Radius	2670 mm

Drive and Brake
Max. Travel Speed	5.5 km/h	Gradeability	70% (35°)

Hydraulic System
Main Pump Type	2 Variable Displacement Piston Pumps	Main Pump max. Oil Flow	2 x 112 LPM
Swing Circuit	285 kg/cm²	Travel Circuit	330 kg/cm²

Refill Capacity
Fuel Tank Capacity	270 L	Engine Oil and Filter	11.5 L
Hydraulic System	210 L	Hydraulic Tank Capacity	124 L

Weight and ground Pressure
Operating Weight	14000 kg	Ground Pressure	0.43 kg/cm²

Dimensions
Overall Length	7870 mm	Overall Height	2860 mm
Bucket Capacity	0.72 m³	Track Gauge	2000 mm
Ground Clearance	440 mm

Working Ranges
Max. Dumping Height	5750 mm	Max. Digging Depth	5150 mm
Max. Vertical Wall Digging Depth	4900 mm	Max. Digging Reach	7920 mm
Max. Digging Reach at Ground Level	7770 mm	Boom Length	4600 mm
Arm Length	2100 mm	Bucket Digging Force	8900-10400 kgf
Arm Crowding Force	7500-7900 kgf

Engine
Model	Kirloskar 4R1040T
Engine Gross Power	105 Hp @ 2200 rpm
Max. Torque	37.5 Nm @ 1500 rpm

Undercarriage
No. of Shoes	46
No. of Upper Rollers	1
No. of Bottom Rollers	7
Track Shoe Width	500 mm

Swing System
Max. Swing Speed	12.0 rpm
Min. Swing Radius	2670 mm

Drive and Brake
Max. Travel Speed	5.5 km/h
Gradeability	70% (35°)

Hydraulic System
Main Pump Type	2 Variable Displacement Piston Pumps
Main Pump max. Oil Flow	2 x 112 LPM
Swing Circuit	285 kg/cm²
Travel Circuit	330 kg/cm²

Refill Capacity
Fuel Tank Capacity	270 L
Engine Oil and Filter	11.5 L
Hydraulic System	210 L
Hydraulic Tank Capacity	124 L

Weight and ground Pressure
Operating Weight	14000 kg
Ground Pressure	0.43 kg/cm²

Dimensions
Overall Length	7870 mm
Overall Height	2860 mm
Bucket Capacity	0.72 m³
Track Gauge	2000 mm
Ground Clearance	440 mm

Working Ranges
Max. Dumping Height	5750 mm
Max. Digging Depth	5150 mm
Max. Vertical Wall Digging Depth	4900 mm
Max. Digging Reach	7920 mm
Max. Digging Reach at Ground Level	7770 mm
Boom Length	4600 mm
Arm Length	2100 mm
Bucket Digging Force	8900-10400 kgf
Arm Crowding Force	7500-7900 kgf
