JCB 385LC

JCB 385LC Hydraulic Excavator excels in versatility and effectiveness, making it suitable for various applications. This High-performance excavator is particularly well-equipped for foundation work, allowing for deep and wide trench digging essential for foundational support in construction projects. The excavator efficiently handles pavement removal, making 385LC Hydraulic Excavator ideal for roadwork and resurfacing tasks, whether dealing with asphalt or concrete. Additionally, it provides the necessary power for slope stabilization, helping to prevent erosion and ensuring safety on construction sites. The JCB 385LC also plays a vital role in flood control projects, capable of digging and moving large quantities of earth to create effective drainage systems and levees, showcasing its reliability in managing challenging conditions. JCB 385LC boasts impressive specifications, featuring an engine gross power of 212 kW and an operating weight of 37,331 kg, which provide substantial performance for demanding tasks. With a maximum digging depth ranging from 6.39 to 6.82 meters, this 385LC Hydraulic Excavator is well-equipped for deep excavation projects. Additionally, its bucket capacity of 1.4 to 2.3 m³ allows for efficient material handling, making the JCB 385LC Hydraulic Excavator an excellent choice for a variety of applications, including foundation work, pavement removal, slope stabilization, and flood control. JCB 385LC Hydraulic Excavator stands out with several unique selling points that enhance its performance and efficiency. Its innovative hydraulic regeneration system recycles oil across the cylinders, resulting in faster cycle times and reduced fuel consumption, leading to significant cost savings. The auto idler feature automatically reduces engine speed when the machine is idle, further conserving fuel and lowering operational costs while keeping the machine ready for immediate use. Enhanced uptime alerts, including fuel and coolant level notifications, facilitate proactive planning and timely service reminders, minimizing downtime and ensuring efficient operation. Additionally, safety features like the swing lock system prevent unintended swing operation, enhancing safety for both operators and surrounding personnel, making the JCB 385LC a reliable choice for busy job sites.

JCB 385LC Features

Engine
Model	JCB DIESELMAX 672 TCAE	Type	4-stroke, 6-Cylinder, High pressure common rail, ECU, turbocharged, intercooled
Engine Gross Power	284 HP(212 KW) @ 2000 rpm	Max. Torque	1150 Nm @ 1400 rpm
Displacement	7.2 L

Undercarriage
No. of Shoes	48	No. of Upper Rollers	2
No. of Bottom Rollers	9	Track Shoe Width	600 mm

Swing System
Max. Swing Speed	8.9 rpm	Min. Swing Radius	4.4-4.49 m

Drive and Brake
Max. Travel Speed	5.3 km/h	Gradeability	35°(70%)

Hydraulic System
Main Pump Type	2 variable displacement axial piston	Main Pump max. Oil Flow	2x304 lpm
Swing Circuit	284 bar	Travel Circuit	343 bar

Refill Capacity
Fuel Tank Capacity	590 L	Engine Oil and Filter	25 L
Hydraulic System	430 L	Hydraulic Tank Capacity	239 L

Weight and Ground Pressure
Operating Weight	37331-38027 kg	Ground Pressure	0.49-0.72 kg/cm²

Dimensions
Overall Lenght	11.33-11.41 m	Overall Height	3.79-3.84 m
Bucket Capacity	1.4-2.3 m³	Track Gauge	2.60 m
Ground Clearance	507 mm

Working Ranges
Max. Dumping Height	6.66-6.85 m	Max. Digging Depth	6.39-6.82 m
Max. Vertical Wall Digging Depth	5.41-5.86 m	Max. Digging Reach	10.18-10.58 m
Max. Digging Reach at Ground Level	9.97-10.38 m	Arm Length	2.21-2.63 m
Bucket Digging Force	262.7 kNm	Arm Crowding Force	223.8-254.9 kNm

Engine
Model	JCB DIESELMAX 672 TCAE
Type	4-stroke, 6-Cylinder, High pressure common rail, ECU, turbocharged, intercooled
Engine Gross Power	284 HP(212 KW) @ 2000 rpm
Max. Torque	1150 Nm @ 1400 rpm
Displacement	7.2 L

Undercarriage
No. of Shoes	48
No. of Upper Rollers	2
No. of Bottom Rollers	9
Track Shoe Width	600 mm

Swing System
Max. Swing Speed	8.9 rpm
Min. Swing Radius	4.4-4.49 m

Drive and Brake
Max. Travel Speed	5.3 km/h
Gradeability	35°(70%)

Hydraulic System
Main Pump Type	2 variable displacement axial piston
Main Pump max. Oil Flow	2x304 lpm
Swing Circuit	284 bar
Travel Circuit	343 bar

Refill Capacity
Fuel Tank Capacity	590 L
Engine Oil and Filter	25 L
Hydraulic System	430 L
Hydraulic Tank Capacity	239 L

Weight and Ground Pressure
Operating Weight	37331-38027 kg
Ground Pressure	0.49-0.72 kg/cm²

Dimensions
Overall Lenght	11.33-11.41 m
Overall Height	3.79-3.84 m
Bucket Capacity	1.4-2.3 m³
Track Gauge	2.60 m
Ground Clearance	507 mm

Working Ranges
Max. Dumping Height	6.66-6.85 m
Max. Digging Depth	6.39-6.82 m
Max. Vertical Wall Digging Depth	5.41-5.86 m
Max. Digging Reach	10.18-10.58 m
Max. Digging Reach at Ground Level	9.97-10.38 m
Arm Length	2.21-2.63 m
Bucket Digging Force	262.7 kNm
Arm Crowding Force	223.8-254.9 kNm
