JCB 37C HD Mini Excavator is expertly designed to tackle a wide range of applications. This mini excavator excels in site clean-up, efficiently removing debris to prepare areas for further development, ensuring a clean and organized work environment. In renovation projects, 37C HD Mini Excavator proves ideal for both digging and demolition tasks, simplifying the process of updating and enhancing existing structures. As a reliable companion on construction sites, the JCB 37C HD handles earthmoving, trenching, and material handling with remarkable ease. Additionally, JCB 37C HD is perfect for landscaping, allowing for precise shaping of terrain, installation of landscaping features, and maintenance of gardens, making outdoor spaces both functional and aesthetically pleasing. JCB 37C HD boasts impressive specifications that enhance its performance across various tasks. With an engine gross power of 18.9 kW, 37C HD Mini Excavator delivers robust performance suitable for demanding applications. Weighing 4,052 kg, this mini excavator strikes a balance between stability and maneuverability. Its max digging depth of 3.48 m allows for efficient excavation in various soil conditions, while the max dump height of 3.54 m facilitates effective material handling and loading, making JCb 37C HD Mini Excavator an excellent choice for construction, landscaping, and renovation projects. JCB 37C HD Mini Excavator is equipped with several unique selling points that enhance its usability and efficiency. Its wide-opening steel bonnet allows for easy access to components, significantly reducing maintenance time and boosting productivity with minimal downtime. The conventional tail swing (CTS) design enhances maneuverability in tight spaces, decreasing rear overhang outside the tracks for better control and stability. Additionally, the clean four-plate dipper design increases structural strength and durability, making JCB 37C HD capable of withstanding the rigors of demanding applications. For safety, the JCB 2GO system ensures that the hydraulics can only be operated when in a secure lockable position, providing peace of mind during operation.
Engine | |||
---|---|---|---|
Model | Perkins 403J-17 | Type | Water cooled diesel engine |
Engine Gross Power | 18.9 KW @ 2200 rpm | Max. Torque | 91.9 Nm @ 1600 rpm |
|
Undercarriage | |||
---|---|---|---|
No. of Upper Rollers | 1 | No. of Bottom Rollers | 4 |
Track Shoe Width | 300 mm |
Swing System | |||
---|---|---|---|
Max. Swing Speed | 8.3 rpm | Min. Swing Radius | 1.65-2.16 m |
Drive and Brake | |||
---|---|---|---|
Max. Travel Speed | 4.5 km/h |
Hydraulic System | |||
---|---|---|---|
Main Pump Type | Variable Displacement Piston | Main Pump max. Oil Flow | 76 lpm @ 2000 rpm |
Refill Capacity | |||
---|---|---|---|
Fuel Tank Capacity | 50 L | Engine Oil and Filter | 6.2 L |
Hydraulic System | 47.5 L | Hydraulic Tank Capacity | 28 L |
Weight and Ground Pressure | |||
---|---|---|---|
Operating Weight | 4052 kg |
Dimensions | |||
---|---|---|---|
Overall Length | 4.81 m | Overall Height | 2.48 m |
Bucket Capacity | 0.11 m³ | Track Gauge | 1.2 m |
|
Working Ranges | |||
---|---|---|---|
Max. Dumping Height | 3.54 m | Max. Digging Depth | 3.34-3.48 m |
Max. Vertical Wall Digging Depth | 1.87 m | Max. Digging Reach | 5.14 m |
|
Engine | |
---|---|
Model | Perkins 403J-17 |
Type | Water cooled diesel engine |
Engine Gross Power | 18.9 KW @ 2200 rpm |
Max. Torque | 91.9 Nm @ 1600 rpm |
Displacement | 1.66 L |
|
Undercarriage | |
---|---|
No. of Upper Rollers | 1 |
No. of Bottom Rollers | 4 |
Track Shoe Width | 300 mm |
Swing System | |
---|---|
Max. Swing Speed | 8.3 rpm |
Min. Swing Radius | 1.65-2.16 m |
Drive and Brake | |
---|---|
Max. Travel Speed | 4.5 km/h |
Hydraulic System | |
---|---|
Main Pump Type | Variable Displacement Piston |
Main Pump max. Oil Flow | 76 lpm @ 2000 rpm |
Refill Capacity | |
---|---|
Fuel Tank Capacity | 50 L |
Engine Oil and Filter | 6.2 L |
Hydraulic System | 47.5 L |
Hydraulic Tank Capacity | 28 L |
Weight and Ground Pressure | |
---|---|
Operating Weight | 4052 kg |
Dimensions | |
---|---|
Overall Length | 4.81 m |
Overall Height | 2.48 m |
Bucket Capacity | 0.11 m³ |
Track Gauge | 1.2 m |
Ground Clearance | 275 mm |
|
Working Ranges | |
---|---|
Max. Dumping Height | 3.54 m |
Max. Digging Depth | 3.34-3.48 m |
Max. Vertical Wall Digging Depth | 1.87 m |
Max. Digging Reach | 5.14 m |
Max. Digging Reach at Ground Level | 5.02 m |
Boom Length | 2.45 m |
Arm Length | 1.60 m |
Bucket Digging Force | 32.4 kN |
Arm Crowding Force | 19.7 kN |
|
