Sany SY580C-10HD
Sany SY580C-10HD

Sany SY580C-10HD

SANY SY580C-10HD Mining Excavator is highly versatile, excelling in a variety of applications, including forestry, marine construction, snow removal, and foundation work. Its powerful digging capacity and large bucket allow for efficient land clearing, material handling, and tough terrain operations in forestry. In marine construction, SY580C-10HD Mining Excavator supports dredging, foundation work, and pier construction, thanks to its deep digging reach and heavy-duty structure. During snow removal, its robust hydraulics and high operational weight enable it to clear large volumes of snow and ice efficiently. Additionally, the SY580C-10HD performs excavation and material handling tasks with precision, making SANY SY580C-10HD an ideal choice for large-scale foundation projects.


SANY SY580C-10HD is powered by a 403 hp engine and offers a maximum digging depth of 7.09 meters. With an operating weight of 52 tons, it is designed to handle heavy-duty tasks with ease. SY580C-10HD Mining Excavator is equipped with a bucket capacity ranging from 2.5 to 3.6 m³, making SANY SY580C-10HD Mining Excavator well-suited for a wide range of demanding applications, including excavation, material handling, and foundation work, all while ensuring high performance in challenging environments.


SANY SY580C-10HD Mining Excavator is engineered for reliability under heavy load conditions, ensuring optimal performance even in the most demanding environments. Every component of the machine undergoes comprehensive testing to guarantee its durability and high uptime, making SY580C-10HD Mining Excavator a trusted choice for intensive operations. Enhanced with durability-improving internal baffle plates, the excavator's structural integrity is reinforced for extended operation in tough conditions. Additionally, the SANY SY580C-10HD prioritizes operator safety with its ergonomic design and secure operational features, ensuring a productive and risk-free working environment on the job site.

Sany SY580C-10HD Key Specifications

Sany SY580C-10HD Features

Engine

Model Isuzu 6WG1X
Type 6 cylinder, inline, water cooled
Engine Gross Power 403 hp(300 kw) @ 1800 rpm
Max. Torque 1950 Nm @ 1400 rpm
Displacement 15.68 L

Undercarriage

No. of Shoes 50
No. of Upper Rollers 2
No. of Bottom Rollers 9
Track Shoe Width 600 mm

Swing System

Max. Swing Speed 8 rpm
Min. Swing Radius 9100 mm

Drive and Brake

Max. Travel Speed 5.4 km/h
Gradeability 70%(35°)

Hydraulic System

Main Pump Type 2 variable displacement axial piston pumps
Main Pump max. Oil Flow 2 x 366 lpm
Swing Circuit 26.9 MPa
Travel Circuit 31.4 MPa

Refill Capacity

Fuel Tank Capacity 680 L
Engine Oil and Filter 50 L
Hydraulic Tank Capacity 480 L

Weight and Ground Pressure

Operating Weight 52000 kg
Ground Pressure 87.1 kPa

Dimensions

Overall Length 12076 mm
Overall Height 3700 mm
Bucket Capacity 3.5 m³
Track Gauge 2740 mm
Ground Clearance 560 mm

Working Ranges

Max. Dumping Height 7255 mm
Max. Digging Depth 7096 mm
Max. Digging Reach 11489 mm
Boom Length 7000 mm
Arm Length 2800 mm
Bucket Digging Force 270 kN
Arm Crowding Force 244 kN
