Hyundai R130 SMART

Hyundai R130 Smart Hydraulic Excavator is engineered for versatility and excels in various applications, including landscaping, where it effectively handles grading and earthmoving to create stunning outdoor spaces. In road construction, it efficiently tackles tasks such as trenching, excavation, and surface preparation for new roads. R130 Smart Hydraulic Excavator is also ideal for utilities and pipeline installation, offering precision in digging and laying pipelines and cables. Additionally, its capabilities extend to dredging, allowing it to manage tasks in water bodies, making Hyundai R130 an invaluable asset for maintaining waterways and ports. Hyundai R130 Smart boasts impressive specifications, featuring an engine gross power of 70.1 kW that delivers reliable performance for various tasks. It is equipped with a fuel tank capacity of 250 liters, ensuring extended operation without frequent refueling. With a maximum digging depth of 4770 mm, Hyundai R130 Smart Hydraulic Escavator is well-suited for deep excavations and site preparation. Additionally, its operating weight of 12,100 kg provides the stability and strength necessary for handling demanding jobs across different applications. Hyundai R130 Smart Hydraulic Excavator is a versatile machine powered by a robust Kirloskar 4R1040T Diesel Engine, delivering optimal performance for various digging and lifting tasks. Designed for extended operations with its substantial fuel tank capacity, R130 Smart Hydraulic Excavator minimizes downtime due to refueling, making Hyundai R130 Smart ideal for demanding job sites. It features an advanced hydraulic system that ensures smooth operation and precise control, enhancing productivity while reducing operator fatigue. Additionally, the Intelligent CAPO System automatically adjusts engine power and hydraulic flow according to working conditions, maximizing fuel efficiency. To further enhance safety, the anti-restart function prevents the engine from restarting while the operator is in the cab, significantly reducing accident risks and ensuring a secure working environment.

Hyundai R130 SMART Features

Engine
Model	Kirloskar 4R1040T	Engine Gross Power	94 HP(70.1 KW) @ 1950 rpm
Max. Torque	357 Nm @ 1550 rpm

Undercarriage
No. of Shoes	41	No. of Upper Rollers	1
No. of Bottom Rollers	6	Track Shoe Width	500 mm

Swing System
Max. Swing Speed	12 rpm	Min. Swing Radius	2380 mm

Drive and Brake
Max. Travel Speed	5.5 km/h	Gradeability	70% (35°)

Hydraulic System
Main Pump Type	2 Variable Displacement Piston Pumps	Main Pump max. Oil Flow	2 x 112 LPM
Swing Circuit	240 kg/cm²	Travel Circuit	330 kg/cm²

Refill Capacity
Fuel Tank Capacity	250 L	Engine Oil and Filter	11.5 L
Hydraulic System	180 L	Hydraulic Tank Capacity	100 L

Weight and Ground Pressure
Operating Weight	12100 kg	Ground Pressure	0.35 kg/cm²

Dimensions
Overall Length	7240 mm	Overall Height	2800 mm
Bucket Capacity	0.65 m³	Track Gauge	1990 mm
Ground Clearance	440 mm

Working Ranges
Max. Dumping Height	5540 mm	Max. Digging Depth	4770 mm
Max. Vertical Wall Digging Depth	4070 mm	Max. Digging Reach	7460 mm
Max. Digging Reach at Ground Level	7320 mm	Boom Length	4300 mm
Arm Length	1960 mm	Bucket Digging Force	8000-9200 kgf
Arm Crowding Force	6140-6410 kgf

Engine
Model	Kirloskar 4R1040T
Engine Gross Power	94 HP(70.1 KW) @ 1950 rpm
Max. Torque	357 Nm @ 1550 rpm

Undercarriage
No. of Shoes	41
No. of Upper Rollers	1
No. of Bottom Rollers	6
Track Shoe Width	500 mm

Swing System
Max. Swing Speed	12 rpm
Min. Swing Radius	2380 mm

Drive and Brake
Max. Travel Speed	5.5 km/h
Gradeability	70% (35°)

Hydraulic System
Main Pump Type	2 Variable Displacement Piston Pumps
Main Pump max. Oil Flow	2 x 112 LPM
Swing Circuit	240 kg/cm²
Travel Circuit	330 kg/cm²

Refill Capacity
Fuel Tank Capacity	250 L
Engine Oil and Filter	11.5 L
Hydraulic System	180 L
Hydraulic Tank Capacity	100 L

Weight and Ground Pressure
Operating Weight	12100 kg
Ground Pressure	0.35 kg/cm²

Dimensions
Overall Length	7240 mm
Overall Height	2800 mm
Bucket Capacity	0.65 m³
Track Gauge	1990 mm
Ground Clearance	440 mm

Working Ranges
Max. Dumping Height	5540 mm
Max. Digging Depth	4770 mm
Max. Vertical Wall Digging Depth	4070 mm
Max. Digging Reach	7460 mm
Max. Digging Reach at Ground Level	7320 mm
Boom Length	4300 mm
Arm Length	1960 mm
Bucket Digging Force	8000-9200 kgf
Arm Crowding Force	6140-6410 kgf
