Liugong 908E Hydraulic Excavator is a versatile machine designed for various heavy-duty applications. In construction, it’s ideal for foundational work, trenching, and material handling. For mining operations, 908E Hydraulic Excavator excels in material transport, earthmoving, and site preparation. This heavy duty excavator also performs efficiently in demolition tasks, including precise tearing down of structures and debris removal. Additionally, Liugong 908E is well-suited for landscaping, handling grading, digging, and other earthmoving tasks to aid in efficient site preparation.


Liugong 908E offers a powerful and efficient performance with its 62 hp engine and a robust operating weight of 7,500 kg, making Liugong 908E Hydraulic Excavator well-suited for a range of heavy-duty applications. It has a bucket capacity of 0.32 m³ and a maximum digging depth of 4,030 mm, providing the capability for deep excavation and effective material handling on various job sites.


Liugong 908E Hydraulic Excavator stands out with several unique selling points that make this heavy duty excavator a top choice for demanding work environments. Its Yanmar 4TNV98 engine offers excellent fuel efficiency and dependable power with low emissions, aligning with modern environmental standards. Equipped with a variable displacement piston hydraulic pump, 908E Hydraulic Excavator ensures smooth and precise operation, even under heavy loads. The hydrostatic drive system provides exceptional control and maneuverability, making Liugong 908E ideal for various terrains. Additionally, the axial piston swing motor enhances the excavator’s swing efficiency and speed, boosting productivity during excavation tasks.

Liugong 908E Key Specifications

Liugong 908E Features

Engine

Model 4TNV98
Engine Gross Power 62 hp @ 2200 rpm
Max. Torque 245 Nm @ 1650 rpm
Displacement 3.3 L

Undercarriage

No. of Shoe 39
No. of Upper Rollers 1
No. of Bottom Rollers 5
Track Shoe Width 450 mm

Swing System

Max. Swing Speed 12 rpm
Min. Swing Radius 1785 mm

Drive and Brake

Max. Travel Speed 5.3 km/h
Gradeability 70%(35°)

Hydraulic System

Main Pump Type Variable displacement piston pump
Main Pump max. Oil Flow 158.4 lpm
Swing Circuit 23.5 MPa
Travel Circuit 29.4 MPa

Refill Capacity

Fuel Tank Capacity 140 L
Engine Oil and Filter 11.6 L
Hydraulic System 110 L
Hydraulic Tank Capacity 80 L

Weight and Ground Pressure

Operating Weight 7500 kg
Ground Pressure 33.3 kPa

Dimensions

Overall Length 6100 mm
Overall Height 2698 mm
Bucket Capacity 0.32 m³
Track Gauge 450 mm
Ground Clearance 383 mm

Working Ranges

Max. Dumping Height 5080 mm
Max. Digging Depth 4030 mm
Max. Vertical Wall Digging Depth 3240 mm
Max. Digging Reach 6270 mm
Max. Digging Reach at Ground 6125 mm
Boom Length 3710 mm
Arm Length 1650 mm
Bucket Digging Force 56 kN
Arm Crowding Force 36 kN
