Tata Hitachi TL340H Prime Wheel Loader is designed for optimal performance across various applications, including construction, mining, waste management, landscaping, and agriculture. For businesses seeking a robust and efficient wheel loader, the Tata Hitachi TL340H Prime is the ideal solution. Its powerful specifications, including a high payload capacity and advanced hydraulic system, ensure enhanced productivity and safety in demanding environments. Equipped with innovative features that improve efficiency and operator comfort, the Tata Hitachi TL340H Prime is a valuable asset for various industries. Tata Hitachi TL340H Prime is equipped with a powerful 121 HP engine and an operating weight ranging from 10,980 to 11,060 KG. It features a bucket capacity of 1.5 to 2.7 m³, ensuring efficient material loading and transport. With an impressive maximum operating height of 4786 mm, it allows for versatile material handling, making it an essential tool on any job site. Tata Hitachi TL340H Prime stands out with its advanced Hydrostatic Drive Technology, which ensures smooth operation and precise control. The Auto Braking System enhances safety by providing reliable braking capabilities, while the gearless drive feature simplifies operation and reduces maintenance requirements. Tata Hitachi TL340H Prime Wheel Loader will enhance productivity and safety in your operations, ensuring optimal results in your projects.
Engine | |||
---|---|---|---|
Model | Cummins B4.5 CIV121D221 | Engine Gross Power | 121 HP @ 2200 rpm |
Max. Torque | 500 Nm @ 1500 rpm | Displacement | 4.5 L |
Electrical System | |||
---|---|---|---|
Battery | 2x12 V |
Transmission | |||
---|---|---|---|
Transmission Type | Electro hydraulically controlled hydrostatic transmission |
Steering System | |||
---|---|---|---|
Steering Type | Articulated frame steering | Turning Radius Outside of Wheel | 5165 mm |
Drive and Brake | |||
---|---|---|---|
Service Brake | Self-adjusting wet type disc brake | Parking Brake | Solenoid actuated spring applied hydraulically released at front axle |
Tyres | |||
---|---|---|---|
Tyre size | 14x25 20 PR |
Hydraulic System | |||
---|---|---|---|
Main Pump | Load sensing variable displacement axial piston pump | Main Pump Flow Rate | 132 lpm @ 2200 rpm |
Raise Time | 5.2 Sec. | Dump Time | 1.2 Sec. |
|
Axles | |||
---|---|---|---|
Front Axle Type | Fixed to front frame | Rear Axle Type | Center pivot on main frame (Oscillating type) |
Refill Capacity | |||
---|---|---|---|
Fuel Tank Capacity | 165 L | Engine Oil Capacity | 17 L |
Axle Oil Capacity | 34.5 L | Hydraulic Oil Capacity | 130 L |
Operating Weight | |||
---|---|---|---|
Operating Weight | 10980 kg |
Dimensions | |||
---|---|---|---|
Static Tipping Load | 8264 kg | Overall Length | 7200 mm |
Bucket Capacity | 1.8 m³ | Max. Digging Depth | 79 mm |
|
Engine | |
---|---|
Model | Cummins B4.5 CIV121D221 |
Engine Gross Power | 121 HP @ 2200 rpm |
Max. Torque | 500 Nm @ 1500 rpm |
Displacement | 4.5 L |
Electrical System | |
---|---|
Battery | 2x12 V |
Transmission | |
---|---|
Transmission Type | Electro hydraulically controlled hydrostatic transmission |
Steering System | |
---|---|
Steering Type | Articulated frame steering |
Turning Radius Outside of Wheel | 5165 mm |
Drive and Brake | |
---|---|
Service Brake | Self-adjusting wet type disc brake |
Parking Brake | Solenoid actuated spring applied hydraulically released at front axle |
Tyres | |
---|---|
Tyre size | 14x25 20 PR |
Hydraulic System | |
---|---|
Main Pump | Load sensing variable displacement axial piston pump |
Main Pump Flow Rate | 132 lpm @ 2200 rpm |
Raise Time | 5.2 Sec. |
Dump Time | 1.2 Sec. |
Lower Time | 3.1 Sec. |
Total Hydraulic Cycle Time | 9.5 Sec |
|
Axles | |
---|---|
Front Axle Type | Fixed to front frame |
Rear Axle Type | Center pivot on main frame (Oscillating type) |
Refill Capacity | |
---|---|
Fuel Tank Capacity | 165 L |
Engine Oil Capacity | 17 L |
Axle Oil Capacity | 34.5 L |
Hydraulic Oil Capacity | 130 L |
Operating Weight | |
---|---|
Operating Weight | 10980 kg |
Dimensions | |
---|---|
Static Tipping Load | 8264 kg |
Overall Length | 7200 mm |
Bucket Capacity | 1.8 m³ |
Max. Digging Depth | 79 mm |
Wheelbase | 2840 mm |
Ground Clearance | 479 mm |
|
