Sany SY20U
Sany SY20U

Sany SY20U

SANY SY20U Mini Excavator is a versatile machine designed for a wide range of applications, including marine construction, where it excels in tasks such as dock work and waterway maintenance. Its compact design allows for easy access to tight spaces while delivering high power and performance for digging, lifting, and material handling. The SY20U Mini Excavator is also ideal for snow removal in urban environments, offering excellent maneuverability and digging depth to clear streets and parking lots. In foundation work, it provides precise digging and material handling capabilities, making it a great choice for small-scale construction projects. Additionally, the SANY SY20U is highly effective in pavement removal, offering the strength and versatility needed to break and remove pavement efficiently.


SANY SY20U is equipped with a 19.8 hp engine, providing a solid power output for various applications. It boasts a maximum digging depth of 2.38 meters and an operating weight of 1.98 tons, making SY20U Mini Excavator compact yet capable for a wide range of tasks. With a bucket capacity of 0.05 cubic meters, the SANY SY20U Mini Excavator is designed to deliver efficient performance in tight spaces, excelling in projects like foundation work, snow removal, and marine construction, where its size and versatility are key advantages.


SANY SY20U Mini Excavator stands out with its compact design and Zero Tail Swing (ZTS), allowing the upper frame to rotate within the width of its tracks, making SY20U Mini Excavator perfect for working in confined spaces and tight urban environments. This versatile machine excels in applications like snow removal, foundation work, and pavement removal, thanks to its compact size and powerful engine. Powered by a reliable Yanmar engine, the SANY SY20U offers long-lasting durability and strong performance for demanding tasks. Its advanced load-sensing hydraulic system ensures optimal flow and fuel efficiency, delivering smoother operation, reduced fuel consumption, and increased productivity.

Sany SY20U Key Specifications

Sany SY20U Features

Engine

Model Yanmar 3TNV80F
Type 4 Stroke, 3 cylinder, water cooled
Engine Gross Power 19.8 hp(14.6 kw) @ 2400 rpm
Max. Torque 67.4 Nm @ 1800 rpm
Displacement 1.22 L

Undercarriage

No. of Shoes 37
No. of Upper Rollers 2
No. of Bottom Rollers 3
Track Shoe Width 230 mm

Swing System

Max. Swing Speed 10 rpm
Min. Swing Radius 1655 mm

Drive and Brake

Max. Travel Speed 4.2 km/h
Gradeability 35%(70°)

Hydraulic System

Main Pump Type Variable displacement axial piston pump
Main Pump max. Oil Flow 70 lpm
Swing Circuit 16.3 MPa
Travel Circuit 24.5 MPa

Refill Capacity

Fuel Tank Capacity 21 L
Engine Oil and Filter 2 L
Hydraulic Tank Capacity 21 L

Weight and Ground Pressure

Operating Weight 1980 kg
Ground Pressure 30 kPa

Dimensions

Overall Length 3515 mm
Overall Height 2495 mm
Bucket Capacity 0.05 m³
Track Gauge 750-1120 mm
Ground Clearance 160 mm

Working Ranges

Max. Dumping Height 2350 mm
Max. Digging Depth 2385 mm
Max. Vertical Wall Digging Depth 2100 mm
Max. Digging Reach 4010 mm
Boom Length 1810 mm
Arm Length 1130 mm
Bucket Digging Force 15.3 kN
Arm Crowding Force 9.2 kN
