Komatsu PC350LC-8M0 Hydraulic Excavator is exceptionally well-suited for a variety of demanding applications. It excels in rubble removal, where its powerful digging force and precise control enable the efficient clearance of large debris. In environmental remediation projects, the excavator reliably handles contaminated or uneven terrains, making PC350LC-8M0 Hydraulic Excavator ideal for restoring affected areas. Its capabilities also extend to agricultural development, where it ensures efficient land preparation and soil management. Additionally, the Komatsu PC350LC-8M0 is effective in soil compaction, contributing to land stabilization and preparation for construction, thereby enhancing productivity and safety on job sites.


Komatsu PC350LC-8M0 is engineered for maximum power and efficiency, making it ideal for heavy-duty excavation and construction projects. With an impressive engine gross power of 194 kW and a bucket digging force ranging from 20,400 to 26,400 kgf, this excavator provides the strength and precision necessary for challenging tasks. PC350LC-8M0 Hydraulic Excavator boasts an operating weight between 34,350 and 34,650 kg, along with a maximum digging depth of 6,100 to 7,385 mm, ensuring Komatsu PC350LC-8M0 Hydraulic Excavator excels in demanding environments. This combination of features guarantees superior productivity across a wide array of construction and earthmoving applications.


Komatsu PC350LC-8M0 Hydraulic Excavator boasts several key features that enhance its performance and efficiency for heavy-duty tasks. PC350LC-8M0 Hydraulic Excavator is powered by the Komatsu SAA6D114E-3 engine, which utilizes direct fuel injection and turbocharging to ensure high efficiency while minimizing emissions and fuel consumption. The excavator's hydrostatic swing system allows for smooth and efficient swing operations, making Komatsu PC350LC-8M0 particularly effective in confined or heavy-load environments. Additionally, the closed-center hydraulic system is equipped with load-sensing and pressure-compensated valves, providing enhanced control and precision during operation. Finally, its heavy-duty hydraulic pump, featuring dual variable displacement piston pumps, delivers reliable hydraulic power that is specifically designed for intensive work applications, ensuring optimal productivity on the job site.

Komatsu PC350LC-8M0 Key Specifications

Komatsu PC350LC-8M0 Features

Engine

Model Komatsu SAA6D114E-3
Type Water-cooled, 4-cycle, direct injection, Turbocharged, aftercooled
Engine Gross Power 260 hp(194 kw) @ 1950 rpm
Displacement 8.27 L

Undercarriage

No. of Shoes 48
No. of Upper Rollers 2
No. of Bottom Rollers 8
Track Shoe Width 600 mm

Swing System

Max. Swing Speed 9.5 rpm
Min. Swing Radius 4325-4470 mm

Drive and Brake

Max. Travel Speed 5.5 km/h
Gradeability 70%(35°)

Hydraulic System

Main Pump Type Two variable displacement piston type
Main Pump max. Oil flow 535 lpm
Swing Circuit 27.9 lpm
Travel Circuit 37.3 lpm

Refill Capacity

Fuel Tank Capacity 605 L
Engine Oil and Filter 37 L
Hydraulic Tank Capacity 188 L

Weight and Ground pressure

Operating Weight 34350 kg
Ground Pressure 63.9 kPa

Dimensions

Overall Length 11245-11405 mm
Overall Height 2850-3480 mm
Bucket Capacity 1.4-2.3 m³
Track Gauge 2590 mm
Ground Clearance 500 mm

Working Ranges

Max. Dumping Height 6365-7040 mm
Max. Digging Depth 6540-7385 mm
Max. Vertical Wall Digging Depth 2870-6270 mm
Max. Digging Reach 10245-11070 mm
Max. Digging Reach at Ground 10045-10895 mm
Boom Length 6470 mm
Arm Length 2220-3185 mm
Bucket Digging Force 200-259 kN
Arm Crowding Force 165-235 kN
