The Tata Hitachi EH5000AC-3 dump truck is mostly used in mining and quarrying industries. It is useful for landscaping, forestry, transporting heavy equipment, and many other applications.


The Tata Hitachi EH5000AC-3 dump truck offers cutting-edge technology and upgraded features, including a fast fuel and oil filling system, advanced suspension, a Hi-Tech ROPS/FOPS cab, and automatic cruise control. These features make the EH5000AC-3 perfect for all heavy-duty work.


The EH5000AC-3 dump truck comes with a powerful 2850 hp engine, spring-applied hydraulic brakes, 500,000 kg of operating weight capacity, and a bucket capacity range between 1.5 to 3.0 m³.

Tata Hitachi EH 5000AC-3 Key Specifications

Tata Hitachi EH 5000AC-3 Features

Engine

Model Cummins QSKTTA60-CE
Engine Gross Power 2850 HP(2125 KW) @ 1900 rpm
Max. Torque 10628 Nm @ 1500 rpm
No. of Cylinders 16
Displacement 60 L

Electrical System

Battery 24 V, 140 Ah
Alternator MTU engine driven alternator.
Starting Motor 24 Volt Electric

Drive and Brake

Service Brake Dry disc (Front Axle), Oil-cooled wet disc (Rear Axle)
Parking Brake Spring applied, hydraulically released brake

Tyres

Tyre Size 53/80R63
Rim Size 914 mm

Suspension

Front Suspension Type Independent tailing arms make up the front axle
Rear Suspension Type "A" frame structure, integral with axle housing

Refill Capacity

Fuel Tank Capacity 2900 L
Cooling System Capacity 725 L

Operating Specifications

Gross Vehicle Weight 500000 kg
Payload Weight 296 T

Dimensions

Overall Length 15490 mm
Overall Height 7520 mm
Overall Width 8610 mm
Ground Clearance 1000 mm
Wheelbase 6470 mm
