Tata Hitachi NX 80 Mini Excavator combines power, efficiency, and advanced technology, ensuring projects are completed effectively and on time. Designed to excel in various applications such as construction, brick kiln operations, desilting, forestry, and utility work, the NX 80 is a powerful and versatile machine. This mini excavator serves as a reliable partner for heavy-duty tasks, delivering exceptional performance across diverse industries. Tata Hitachi NX 80 Mini Excavator delivers a robust engine gross power of 48.31 HP and an operating weight of 7400 kg to 7700 kg, ensuring reliability in demanding environments. With a bucket capacity of 0.35 m³ and a bucket digging force of 5600 kgf, it handles both light and heavy loads efficiently, excelling in tough digging conditions. The excavator's max digging depth of 4060 mm to 4660 mm adds versatility, making it suitable for a wide range of tasks. Tata Hitachi NX 80 Mini Excavator features an advanced Intelligent Optimum Hydraulic System (IOHS) for enhanced hydraulic performance. Its auto idle and auto deceleration system reduces fuel consumption, cutting operational costs. With a rock breaker piping kit, it easily handles tough materials. The NX 80 also offers low maintenance costs.
Engine | |||
---|---|---|---|
Model | Yanmar 4TN98S | Type | Water cooled,4 cylinder in - line diesel engine |
Engine Gross Power | 48.33 HP @ 2100 rpm | Max. Torque | 214 Nm @ 1260 rpm |
Undercarriage | |||
---|---|---|---|
No. of Shoes | 37x2 | No. of Upper Rollers | 1x2 |
No. of Bottom Rollers | 5x2 | Track Shoe Width | 450 mm |
Swing System | |||
---|---|---|---|
Max. Swing Speed | 12.8 rpm | Min. Swing Radius | 1730-2060 mm |
Drive and Brake | |||
---|---|---|---|
Max. Travel Speed | 5 km/h |
Hydraulic System | |||
---|---|---|---|
Main Pump Type | 2 variable displacement axial piston pumps | Main Pump max. Oil Flow | 2x60 lpm |
Swing Circuit | 235 kgf/cm² | Travel Circuit | 280 kgf/cm² |
Refill Capacity | |||
---|---|---|---|
Fuel Tank Capacity | 135 L | Engine Oil and Filter | 10.2 L |
Hydraulic System | 92 L | Hydraulic Tank Capacity | 42 L |
Weight and Ground Pressure | |||
---|---|---|---|
Operating Weight | 7500 kg | Ground Pressure | 0.36 kgf / cm² |
Dimensions | |||
---|---|---|---|
Overall Length | 6050 mm | Overall Height | 2615 mm |
Bucket Capacity | 0.13-0.68 m³ | Ground Clearance | 385 mm |
Working Ranges | |||
---|---|---|---|
Max. Dumping Height | 5050-5470 mm | Max. Digging Depth | 4060-4660 mm |
Max. Vertical Wall Digging Depth | 3600-4060 mm | Max. Digging Reach | 6350-6800 mm |
|
Engine | |
---|---|
Model | Yanmar 4TN98S |
Type | Water cooled,4 cylinder in - line diesel engine |
Engine Gross Power | 48.33 HP @ 2100 rpm |
Max. Torque | 214 Nm @ 1260 rpm |
Undercarriage | |
---|---|
No. of Shoes | 37x2 |
No. of Upper Rollers | 1x2 |
No. of Bottom Rollers | 5x2 |
Track Shoe Width | 450 mm |
Swing System | |
---|---|
Max. Swing Speed | 12.8 rpm |
Min. Swing Radius | 1730-2060 mm |
Drive and Brake | |
---|---|
Max. Travel Speed | 5 km/h |
Hydraulic System | |
---|---|
Main Pump Type | 2 variable displacement axial piston pumps |
Main Pump max. Oil Flow | 2x60 lpm |
Swing Circuit | 235 kgf/cm² |
Travel Circuit | 280 kgf/cm² |
Refill Capacity | |
---|---|
Fuel Tank Capacity | 135 L |
Engine Oil and Filter | 10.2 L |
Hydraulic System | 92 L |
Hydraulic Tank Capacity | 42 L |
Weight and Ground Pressure | |
---|---|
Operating Weight | 7500 kg |
Ground Pressure | 0.36 kgf / cm² |
Dimensions | |
---|---|
Overall Length | 6050 mm |
Overall Height | 2615 mm |
Bucket Capacity | 0.13-0.68 m³ |
Ground Clearance | 385 mm |
Working Ranges | |
---|---|
Max. Dumping Height | 5050-5470 mm |
Max. Digging Depth | 4060-4660 mm |
Max. Vertical Wall Digging Depth | 3600-4060 mm |
Max. Digging Reach | 6350-6800 mm |
Max. Digging Reach at Ground Level | 6190-6660 mm |
Boom Length | 3720 mm |
Arm Length | 1620-2120 mm |
Bucket Digging Force | 5600 kgf |
Arm Crowding Force | 3900 kgf |
|
