Mahindra Roadmaster G9075 Motor Grader stands out as a reliable motor grader designed to meet the challenges of modern road construction while maintaining high standards across various terrains. Built for multiple applications, the Mahindra Roadmaster G9075 is ideal for state highway construction, railway projects, ODR roads, and SH expansion tasks. Whether tackling intricate rail construction or large-scale highway projects, this motor grader delivers the power and precision necessary for efficient and accurate performance. Mahindra Roadmaster G9075, powered by a robust 74 HP engine, ensures top-tier performance for demanding road construction tasks. Roadmaster G9075 Motor Grader's 100-liter fuel tank allows for extended operations without frequent refueling, enhancing productivity. With an impressive ground clearance of 467 mm and a travel speed ranging from 33 to 36.5 km/h, this motor grader ensures rapid movement across job sites. Additionally, the 3000 mm blade is designed for precise grading and finishing, making the Mahindra Roadmaster G9075 an ideal choice for high-quality roadwork and efficient project completion. Mahindra Roadmaster G9075 Motor Grader features an improved hydraulic pump that enhances efficiency by providing smoother and more precise control, even in demanding conditions. A Key feature of Mahindra Roadmaster G9075 is final drive with a differential lock, ensuring excellent traction and stability, particularly on challenging surfaces. This feature significantly boosts performance in tough environments. Additionally, the blade rotation angle of up to 50° from the transverse axis allows for quicker and more efficient grading, making it ideal for confined or tight spaces, further adding to the machine’s versatility.
Engine | |||
---|---|---|---|
Model | BS TREM IV CEV | Engine Gross Power | 74 HP(55 KW) @ 2200 rpm |
Max. Torque | 345 Nm @ 1200-1500 rpm | No. of Cylinders | 4 |
|
Electrical System | |||
---|---|---|---|
Battery | 12 V |
Transmission | |||
---|---|---|---|
Max. Forward Speed | 36.5 km/h | Max. Reverse Speed | 10.5 km/h |
Steering System | |||
---|---|---|---|
Steering Type | Power steering | Steering Angle | 45° (inner), 32° (outer) |
Min. Turning Radius | 10 m |
Drive and Brake | |||
---|---|---|---|
Service Brake | Foot operated hydraulically actuated oil immersed disc in middle axle | Parking Brake | Hand operated mechanically actuated caliper brakes on middle axle |
Tyres | |||
---|---|---|---|
Tyre Size | 13x24-12 PR |
Hydraulic System | |||
---|---|---|---|
Main Pump Type | Fixed displacement tandem gear pump |
Axles | |||
---|---|---|---|
Front Axle Type | Non-driven, steerable central pivoted | Rear Axle Type | Driven, non steerable, central pivoted |
Oscillation Angle | 10° (Upward), 15° (Downward) |
Refill Capacity | |||
---|---|---|---|
Fuel Tank Capacity | 100 L | Engine Oil Capacity | 13.5 L |
Transmission Oil Capacity | 16 L | Hydraulic Oil Capacity | 50 L |
Operating Specifications | |||
---|---|---|---|
Weight on Front Axle | 2688 kg | Weight on Rear Axle | 6180 kg |
Dimensions | |||
---|---|---|---|
Overall Length | 9270 mm | Overall Height | 3290 mm |
Ground Clearance | 467 mm | Wheelbase | 5225 mm |
Engine | |
---|---|
Model | BS TREM IV CEV |
Engine Gross Power | 74 HP(55 KW) @ 2200 rpm |
Max. Torque | 345 Nm @ 1200-1500 rpm |
No. of Cylinders | 4 |
Bore | 96 mm |
Stroke | 122 mm |
Displacement | 3532 cm³ |
|
Electrical System | |
---|---|
Battery | 12 V |
Transmission | |
---|---|
Max. Forward Speed | 36.5 km/h |
Max. Reverse Speed | 10.5 km/h |
Steering System | |
---|---|
Steering Type | Power steering |
Steering Angle | 45° (inner), 32° (outer) |
Min. Turning Radius | 10 m |
Drive and Brake | |
---|---|
Service Brake | Foot operated hydraulically actuated oil immersed disc in middle axle |
Parking Brake | Hand operated mechanically actuated caliper brakes on middle axle |
Tyres | |
---|---|
Tyre Size | 13x24-12 PR |
Hydraulic System | |
---|---|
Main Pump Type | Fixed displacement tandem gear pump |
Axles | |
---|---|
Front Axle Type | Non-driven, steerable central pivoted |
Rear Axle Type | Driven, non steerable, central pivoted |
Oscillation Angle | 10° (Upward), 15° (Downward) |
Refill Capacity | |
---|---|
Fuel Tank Capacity | 100 L |
Engine Oil Capacity | 13.5 L |
Transmission Oil Capacity | 16 L |
Hydraulic Oil Capacity | 50 L |
Operating Specifications | |
---|---|
Weight on Front Axle | 2688 kg |
Weight on Rear Axle | 6180 kg |
Dimensions | |
---|---|
Overall Length | 9270 mm |
Overall Height | 3290 mm |
Ground Clearance | 467 mm |
Wheelbase | 5225 mm |
