JCB 455-4
JCB 455-4

JCB 455-4

JCB 455-4 Wheel Loader is versatile and well-suited for a variety of applications. In material handling at ports and shipping yards, this loader efficiently loads and unloads materials, enhancing logistics and transportation operations. Its robust design and powerful performance make this wheel loader an ideal choice for various construction tasks, including site preparation and material movement. In mining operations, the JCB 455-4 excels at transporting heavy materials, significantly boosting productivity and operational efficiency. Additionally, JCb 455-4 is well-equipped for quarrying applications, where its strength and capacity are crucial for managing large volumes of materials effectively.


JCB 455-4 Wheel Loader boasts impressive specifications that enhance its performance across various applications. 455-4 Wheel Loader features an engine gross power of 167.8 kW, delivering robust power to tackle the toughest jobs with ease. With a loader capacity ranging from 2.5 to 5 m³, JCB 455-4 offers flexibility for diverse material handling needs, making it suitable for different tasks. Its operating weight of 18,000 kg ensures stability and strength during demanding operations, while a fuel tank capacity of 280 L allows for extended working hours without the need for frequent refueling, maximizing productivity on the job site.


JCB 455-4 Wheel Loader stands out with its unique selling points that enhance its operational efficiency and environmental compliance. It incorporates a Common Rail Direct Injection (CRDI) fuel system, which optimizes fuel efficiency and performance, delivering maximum power while minimizing emissions. 455-4 Wheel Loader also features a bigger and wider bucket range, allowing operators to select the ideal bucket for various applications, enhancing versatility on the job. Powered by the proven CEV Stage IV Cummins QSB6.7 engine, JCB 455-4 complies with stringent emissions standards while providing exceptional power and fuel efficiency. Additionally, the IntelliDiagnostic system enables quick and easy troubleshooting, enhancing productivity and minimizing downtime by allowing operators to swiftly diagnose and address any issues.

JCB 455-4 Key Specifications

JCB 455-4 Features

Engine

Model Cummins QSB 6.7 CEV Stage IV
Engine Gross Power 225 hp(168 kW) @ 2200 RPM
Max. Torque 1186 Nm @ 1300 RPM
Displacement 6.7 L

Electrical System

Battery 2 Batteries, 12 V

Transmission

Transmission Type 4 Wheel Drive, Automatic 4 Speed Transmission
Max. Forward Speed 38 km/h
Max. Reverse Speed 26 km/h

Axles

Front Axle Type Limited Slip Differential
Rear Axle Type Limited Slip Differential
Oscillation Angle 12.5°

Drive and Brake

Service Brake Multi-plate Disc Brake Type
Parking Brake Electro-Hydraulic Disc Type

Steering System

Steering Type Hydraulic System with Steer Priority

Tyres

Tyre Size 23.5 x 25-20 PR

Hydraulic System

Main Pump Variable Displacement Piston Pump-Load Sensing
Main Pump Flow 94-132 L/min.

Hydraulic Cycle Times

Raise Time 6.0 Sec.
Dump Time 1.9 Sec.
Lower Time 3.7 Sec.
Total Hydraulic Cycle Time 11.6 Sec.

Refill Capacity

Fuel Tank Capacity 280 L
Hydraulic Oil Capacity 180 L
Transmission Oil Capacity 38 L
Engine Oil Capacity 18 L

Operating Specifications

Operating Weight 17805-18379 kg

Dimensions

Overall Length 8460 mm
Max. Digging Depth 74-153 mm
Loader Bucket Breakout Force 13358-17845 kgf
Bucket Capacity 2.5-5.0 m³
Static Tipping Load 11868-14202 kg
Wheelbase 3300 mm
Ground Clearance 480 mm
