BEML BD14W Wheel Dozer is designed for versatility and is suitable for a wide range of applications. It excels in snow removal, effectively clearing snow from roads and pathways during winter months to ensure safe access. The BD14W Wheel Dozer is also ideal for dams and earthworks, adeptly handling earthmoving tasks involved in dam construction and site preparation. In the context of road construction, it is essential for grading and shaping surfaces for new roads, ensuring proper drainage and stability. Additionally, the BEML BD14W efficiently supports site preparations by preparing land for various construction projects, making it a valuable tool in the construction industry. BEML BD14W is powered by an engine with a gross power ranging from 126 to 148 hp, providing reliable performance for various applications. It features a blade capacity of 2.4 m³, making it effective for earthmoving tasks such as grading and leveling. With an operating weight of 15,000 kg, the BD14W Wheel Dozer ensures stability and durability during operation, even on challenging terrains. Additionally, it is equipped with a fuel tank capacity of 185 L, allowing for extended operational time and reduced downtime on job sites. These specifications highlight the BEML BD14W’s capability to efficiently handle a variety of construction activities. BEML BD14W Wheel Dozer is equipped with advanced features that significantly enhance its operational capabilities. Its Articulated Power Steering provides higher maneuverability and faster cycle times, allowing for precise handling in tight spaces, which is essential for efficient operation on job sites. The BD14W Wheel Dozer features Limited Slip Differential Front and Rear Axles, ensuring positive traction while loading and enhancing productivity across various terrains. Additionally, the Rear Axle Oscillation offers improved stability on rough and uneven surfaces, ensuring consistent performance even in challenging conditions. Finally, the Center Point Articulation facilitates safer steering operations, reducing the risk of accidents on job sites. These innovative features make the BEML BD14W a reliable and effective choice for a variety of construction applications.
Engine | |||
---|---|---|---|
Model | BEML BS6D105-1 | Type | Water cooled 4 cycle, over head valve, direct injection type, turbo charged diesel engine |
Engine Gross Power | 148 HP(110 KW) @ 2000 rpm | Max. Torque | 565 Nm @ 1400 rpm |
|
Electrical System | |||
---|---|---|---|
Battery | 24V (2x12V), 150 Ah |
Transmission | |||
---|---|---|---|
Max. Forward Speed | 31.4 km/h | Max. Reverse Speed | 22.34 km/h |
Transmission Type | Rear mounted multi speed power shift electronic control transmission with four forward & three reverse speeds |
Hydraulic System | |||
---|---|---|---|
Hydraulic Pump Type | Vane Pump | No. of Blade Lift Cylinder | 2 |
Blade Lift Cylinder Bore | 90 mm |
Refill Capacity | |||
---|---|---|---|
Fuel Tank Capacity | 185 L | Transmission & Torque Converter | 27 L |
Operating Specifications | |||
---|---|---|---|
Operating Weight | 15000 kg |
Dimensions | |||
---|---|---|---|
Overall Length | 7120 mm | Blade max. Lift above Ground | 1050 mm |
Blade max. Drop below Ground | 660 mm | Blade Capacity | 2.4 m³ |
|
Engine | |
---|---|
Model | BEML BS6D105-1 |
Type | Water cooled 4 cycle, over head valve, direct injection type, turbo charged diesel engine |
Engine Gross Power | 148 HP(110 KW) @ 2000 rpm |
Max. Torque | 565 Nm @ 1400 rpm |
Bore | 105 mm |
Stroke | 125 mm |
No. of Cylinder | 6 |
Displacement | 6.5 L |
|
Electrical System | |
---|---|
Battery | 24V (2x12V), 150 Ah |
Transmission | |
---|---|
Max. Forward Speed | 31.4 km/h |
Max. Reverse Speed | 22.34 km/h |
Transmission Type | Rear mounted multi speed power shift electronic control transmission with four forward & three reverse speeds |
Hydraulic System | |
---|---|
Hydraulic Pump Type | Vane Pump |
No. of Blade Lift Cylinder | 2 |
Blade Lift Cylinder Bore | 90 mm |
Refill Capacity | |
---|---|
Fuel Tank Capacity | 185 L |
Transmission & Torque Converter | 27 L |
Operating Specifications | |
---|---|
Operating Weight | 15000 kg |
Dimensions | |
---|---|
Overall Length | 7120 mm |
Blade max. Lift above Ground | 1050 mm |
Blade max. Drop below Ground | 660 mm |
Blade Capacity | 2.4 m³ |
Blade Height | 965 mm |
Height to Cab of Top | 3330 mm |
Max. Tilt Adjust | 400 mm |
Ground Clearance | 450 mm |
|
